POWER AND THROUGHPUT
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.

FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.

DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

10G support	Yes
AC input frequency	50/60 Hz
AC input voltage	100 - 240 V
Access Control List (ACL)	Y
Basic switching RJ-45 Ethernet ports type	N
Broadcast storm control	Y
Built-in processor	Y
Cables included	AC,USB Type-C
Console port	RJ-45
Depth	400 mm
DoS attack prevention	Y
Flash memory	512 MB
Flow control support	Y
Form factor	1U
Full duplex	Y
Heat dissipation	374.6 BTU/h
Height	43.2 mm
IGMP snooping	Y
Input current	6.3 A
Internal memory	2048 MB
Jumbo frames support	Y
Latency (1 Gbps)	1.06 µs
Latency (10 Gbps)	0.63 µs
LED indicators	Y
Link aggregation	Y
MAC address filtering	Y
MAC address table	16000 entries
Management protocols	SNMP V1, V2, V3
Mean time between failures (MTBF)	778741 h
Memory type	DDR4-SDRAM
Multicast support	Y
Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1Qav,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ak,IEEE 802.3bz,IEEE 802.3u
Noise level	61.8 dB
Non-operating altitude	0 - 3000 m
Number of VLANs	4093
Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	0 - 90 %
Operating temperature (T-T)	0 - 50 °C
Packet buffer memory	32 MB
Password protection	Y
Power consumption (typical)	119.3 W
Power over Ethernet (PoE)	No
Power source	AC
Power supply	240 W
Power supply included	Y
Processor frequency	1800 MHz
Processor model	ARM Cortex-A57
Quality of Service (QoS) support	Y
Rack mount kit	Y
Rack mounting	Yes
Rate limiting	Y
Routing protocols	OSPF,OSPFv2,OSPFv3,RIP,RIP-1,RIP-2
Spanning tree protocol	Y
Stackable	Yes
Static port security	Y
Storage relative humidity (H-H)	0 - 95 %
Storage temperature (T-T)	-20 - 70 °C
Store-and-forward	Y
Switch layer	L3
Switch type	Managed
Switching capacity	680 Gbit/s
Throughput	505.92 Mpps
USB 2.0 ports quantity	2
User guide	Y
VLAN support	Y
Web-based management	Y
Weight	6250 g
Width	440 mm
ARP inspection	Y
Jumbo frames	12000
Sustainability compliance	Y
SFP28 ports quantity	4
IGMP proxy	Y
IPv4 routes	512
IPv6 routes	256
Compliance certificates	BSMI,CCC,CE,Federal Communications Commission (FCC),Low Voltage Directive (LVD)
6to4 tunnel	Y
