Orbi™ is the simplest and smartest way to enjoy high-speed WiFi in every corner of

your home. Each Add-on Orbi Satellite easily expands your Orbi WiFi System to cover an

additional 2,000 square feet with strong WiFi signals. Innovative Tri-band WiFi helps

maximize the Internet speeds available in your home.

Enjoy better WiFi. Everywhere.



FastLane3™ Technology.

The dedicated WiFi backhaul creates better 4K HD streaming & gaming, even as you connect more devices.



One WiFi Network.

Enjoy the convenience of a single WiFi name for your whole home.



Your Home. Covered.

This Add-on Satellite expands your WiFi coverage up to an additional 2,000 sq ft† with high-performance AC2200 WiFi.



Simple & Secure.

Use the Orbi app or a web browser to create secure whole home WiFi in minutes. With no accounts to set up.
3GN
4GN
AC adapter includedY
Antenna typeinternal
Antennas quantity4
Built-in processorY
DC-in jackY
Depth61 mm
Ethernet LANY
Ethernet LAN (RJ-45) ports2
Ethernet LAN data rates10,100,1000 Mbit/s
Height168 mm
LED indicatorsWLAN
Modulation256-QAM
Networking standardsIEEE 802.3,IEEE 802.3ab,IEEE 802.3u
On/off switchY
Output current1.5 A
Output voltage12 V
Package typebox
Power source typeAC
Processor cores4
Processor frequency710 MHz
Product typeTabletop router
Quick start guideY
Security algorithmsWPA,WPA-PSK
USB portN
Weight476 g
Wi-Fi standards802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Width142 mm
WPS push buttonY
WLAN data transfer rate (first band)400 Mbit/s
WLAN data transfer rate (second band)866 Mbit/s
WLAN data transfer rate (third band)866 Mbit/s

rbs20-100uks.pdf

Netgear RBS20 Data Sheet

Download (665.54k)

Netgear RBS20

RBS20 — Orbi AC2200 Tri-band WiFi Add-on Satellite

RBS20-100UKS

Out of Stock

£143.48
£119.57 Ex VAT.
