FibreFox Quad OTDR
  • FibreFox Quad OTDR
  • FibreFox Quad OTDR
The FF600 has a large LCD touch screen and short-cut keys to make it very easy to operate. The large-capacity polymer lithium battery gives the device enough power to work for up to 8 consecutive hours. Super-large storage capacity of traces all saved on an SD card. The FF600 is abe to meet FTTx testing needs and several wavelengths can be chosen. Solid casing design means the device is not only durable, it is also dustproof and shockproof. Overall, the FF600 boasts intelligent testing, simple to use and is packed full of powerful functions.
Power supplyLithium battery; continuous working hours > 8 hours
Relative humidity0% to 95% (non condensation)
Size150 x 235 x 66mm
Wavelength650nm
Weight1.5 KB
Operating TemperatureRunning Temperature: -10°C to +50°C Memory Temperature: -40°C to +70°C
Optical InterfaceFC/UPC (PC and APC are selectable)
Data InterfaceUSB interface, SD card interface
Output Power (dBm)> -3
Maximum Testing Distance180km

You might also like

  • LC - LC Singlemode (9/125) Duplex Fibre Patch Lead
    LC - LC Singlemode (9/125) Duplex Fibre...
  • FiberMASTER™ Fiber Optic Test Kit
    FiberMASTER™ Fiber Optic Test Kit

Similar products

  • Fibre Optic Tool Kit
    Fibre Optic Tool Kit
  • Epoxy Tool Kit for SC, ST & FC Connectors
    Epoxy Tool Kit for SC, ST & FC Connectors
  • Epoxy Tool Kit for LC Connectors
    Epoxy Tool Kit for LC Connectors
  • XP Fit Assembly Jig
    XP Fit Assembly Jig

FibreFox Quad OTDR

All in one solution for Multimode & Singlemode test requirements.

FF600-OTDR-QUAD

Low Stock

£6,287.40
£5,239.50 Ex VAT.
